02-017 LOWER HYDRAULIC LINES-SK330LC-6E SK330-6E SK350LC-6E Kobelco Excavator Parts Number Electronic Catalog EPC Manuals A23 4 LC02H01064P1 CLAMP A22 4 LC02H01063P1 CLAMP A21 8 ZW26K12000 LOCK WASHER ID 12 x OD 17.8 x Th 2.5mm A20 8 ZS28C12040 SCREW M12x1.75x40mm…
02-016 SHOE ASSEMBLY (SINGLE)-SK330LC-6E SK330-6E SK350LC-6E Kobelco Excavator Parts Number Electronic Catalog EPC Manuals 4 48 LC60DU0008P1 SHOE - 700 mm Single 3 180 LC60D01003P1 BOLT M22x1.5x68mm Long 2 180 2420Z1414 NUT M22x1.5mm 1-11 2 2419T6765 PIN 1-10 86 2445Z1585…
02-015 SHOE ASSEMBLY (HIGH AND WIDE)-SK330LC-6E SK330-6E SK350LC-6E Kobelco Excavator Parts Number Electronic Catalog EPC Manuals 8 49 2424N248 SHOE 900mm, (F5 Only) 7 49 2424N247 SHOE 800mm, (F4 Only) 6 49 LC60DU0013P1 SHOE 700mm, (F3 Only) 5 49 LC60DU0012P1…
02-014 SHOE ASSEMBLY-SK330LC-6E SK330-6E SK350LC-6E Kobelco Excavator Parts Number Electronic Catalog EPC Manuals 10 192 2420Z1414 NUT M22x1.5mm 9 192 LC60D01003P1 BOLT M22x1.5x68mm Long, (F5 Only) 8 192 LC60D01001P1 BOLT M22x1.5x64mm Long, (F1 - F4 Only) 6 48 LC60D00007P1 SHOE…
02-013 UPPER ROLLER ASSEMBLY (HIGH AND WIDE)-SK330LC-6E SK330-6E SK350LC-6E Kobelco Excavator Parts Number Electronic Catalog EPC Manuals 2 16 2420P1615D7 SCREW M22x2.5x105mm 1-8 2 ZE82T04000 PLUG 1/4" PT 1-7 2 ZD11G07000 O-RING ID 69.40 ± 0.61 x OD 75mm 1-6…
02-012 UPPER ROLLER ASSEMBLY-SK330LC-6E SK330-6E SK350LC-6E Kobelco Excavator Parts Number Electronic Catalog EPC Manuals 4 4 ZN13C20016 NUT M20x2.50mm 3 8 ZW13H20000 WASHER ID 20 x OD 40 x Th 4.5mm 2 4 ZS13C20150 SCREW M20x2.50x150mm 1-13 1 2445R440F1 SEAL…
02-011 TRACK ROLLER ASSEMBLY-SK330LC-6E SK330-6E SK350LC-6E Kobelco Excavator Parts Number Electronic Catalog EPC Manuals 2 64 2420P1615D7 SCREW M22x2.5x105mm 1-8 2 ZE82T04000 PLUG 1/4" PT 1-7 2 ZD11G07000 O-RING ID 69.40 ± 0.61 x OD 75mm 1-6 2 2445R442F1 SEAL…
02-010 IDLER ADJUST ASSEMBLY-SK330LC-6E SK330-6E SK350LC-6E Kobelco Excavator Parts Number Electronic Catalog EPC Manuals 11 1 LC54D01005P1 GUARD 10 2 2419T4748 PIN 9 1 2439P174 PISTON 8 ar P1622900N08 OIL SEAL 94mmX90.7mmX2mm, If Used 8 1 ZD12G09000 O-RING ID 89.40…
02-009 IDLER ASSEMBLY-SK330LC-6E SK330-6E SK350LC-6E Kobelco Excavator Parts Number Electronic Catalog EPC Manuals 8 2 ZE82T02000 PLUG Pipe, 1.25" PT 7 2 ZD11G08500 O-RING ID 84.40 ± 0.61 x OD 90mm 6 2 2445R443F1 SEAL FLOATING 4 2 2405P440 BUSHING…
02-008 CRAWLER IDLER ASSEMBLY-SK330LC-6E SK330-6E SK350LC-6E Kobelco Excavator Parts Number Electronic Catalog EPC Manuals 4 2 2444P803 LUBE NIPPLE 5/8" - 18 UNF, Straight 2 2 LC54D00002F1 SHOCK ABSORBER 1 2 LC52D00002F1 IDLER WHEEL AR LC52D00006F1 IDLER WHEEL ASSEMBLY, CRAWLER…
