787846-5001S GT3271LS Turbocharger for Hino J08E Kobelco SK330 SK350-8
787846-5001S GT3271LS Turbocharger | For Hino J08E Kobelco SK350 SK350-8
Product Information
-
- Replacement Brand: Hino / Kobelco application
- Turbocharger Brand: Garrett
- Category: Engine Parts
- Part Number: 787846-5001S
- Part Name: GT3271LS Turbocharger
- Alternative OEM: 7878465001S
- Engine Model: Hino J08E, 7.7L
- Compatible Equipment: Kobelco SK350 and SK350-8; verify model, serial number, and original turbocharger identification
- Condition: New Aftermarket Replacement
Product Function & Specs:
787846-5001S is identified by Garrett as a GT3271LS turbocharger associated with the Hino J08E engine used in selected Kobelco construction equipment applications.
- Turbocharger Model: GT3271LS
- Engine Model: J08E
- Engine Displacement: 7.7L
- Rated Output Listed: 177 HP at 2,100 RPM
- Turbocharger Technology: Wastegated
- Actuation: Pneumatic
Garrett lists OE reference S1760-E0200 for this turbocharger. The original turbocharger nameplate, engine information, and mounting configuration should be checked before ordering.
Failure Symptoms:
- Reduced engine power or slow acceleration under load
- Abnormal turbocharger noise or vibration
- Excessive exhaust smoke or increased oil consumption associated with turbocharger faults
Quick Installation Notes:
- Compare the turbocharger nameplate, part number, housing orientation, and mounting points with the replacement.
- Clean the oil supply and drain lines and inspect the air intake system for contamination.
- Prime the turbocharger lubrication circuit and follow the applicable engine service procedure before operation.
Maintenance Tips:
- Use the specified engine oil and maintain the recommended oil-change intervals.
- Inspect air filters, intake hoses, oil lines, and connections for blockage or leakage.
- Monitor boost performance, unusual noise, smoke, and oil consumption during routine service.
FAQ:
Q: What is 787846-5001S?
A: 787846-5001S is a Garrett GT3271LS turbocharger associated with the Hino J08E 7.7L diesel engine used in selected Kobelco equipment.
Q: Which engine uses this turbocharger?
A: Public Garrett and specialist turbocharger catalogues associate this part with the Hino J08E engine. Confirm the engine identification and original turbocharger nameplate before ordering.
Q: Which Kobelco machines are listed?
A: Listings associate the turbocharger with Kobelco SK350 and SK350-8 excavators. Other applications should be verified individually using the machine serial number.
Q: Is this a genuine Garrett turbocharger?
A: The reference number is a Garrett turbocharger number. This product page describes a new aftermarket replacement and does not claim genuine Garrett factory status.
Q: What should be checked before installation?
A: Check the turbocharger model, OE reference, housing orientation, mounting points, oil connections, and actuator arrangement against the original unit.
